Breaking Down the Components of a Hybrid Electric Vehicle


In light of recent reports of the imminent release of yet another hybrid or electric vehicle, this piece delves deeper into the materials from which such vehicles are constructed. How do they vary from regular gas-powered cars, and what does their future hold? How to find the most popular ev charging stations?

The plug to power it at home is included with electric and hybrid vehicles but is not standard on conventional cars. Neither an electric motor nor a large battery pack is in the classic vehicle. While a battery is present in the classic automobile, it serves only to kickstart the internal combustion engine and as a cushion for the other electrical components. The gas engine is the traditional vehicle’s source of power.

The electric engine and the battery are the two most essential parts of any electric car. The battery provides energy for the journey, which the electric motor uses to propel the vehicle. Regenerative braking is an option on nearly all of them, allowing the driver to charge the battery while slowing down. This is a fantastic strategy for enhancing a vehicle’s general efficiency. In addition, a battery management system (BMS) is commonly used to prevent overcharging, over-discharging, and other potentially damaging battery operations.

In addition to the electric motor, battery, and traditional combustion engine, hybrid vehicles have a few other vital components. (but also a fuel cell is used, for example). Also present is a mechanism for transmitting energy from the battery to the wheels via, say, a combustion motor. Last but not least, power could be supplied to the electric motor using the combustion engine as a generator. The battery stores the surplus energy for later use.

Alternatively, the mechanical power can be transferred to the wheels via a unique gear set that combines the mechanical energy from the combustion engine and the electric motor. Some producers even use a hybrid system, with an internal combustion engine driving one set of wheels and an electronic motor driving the other. The combustion engine provides added power on highways or different ranges, but the electric machine is much more efficient at lower speeds (such as in urban regions).

To recap, the components of an electric car are:

  • Electric Motor
  • Power Source

The components of a hybrid car are:

  • Electric Motor
  • Power Source
  • Power supply (internal combustion engine, fuel cell, etc.)

Electric and hybrid vehicles’ main drawback is their high price tag. They can be more expensive to buy than a regular vehicle. This is due to the high cost of batteries and the fact that conventional cars can be made in large quantities (think one million units versus a thousand),, making them more cost-effective. Batteries are currently the most expensive component of a vehicle, with the expense increasing in proportion to the size of the battery.

The limited range of electric vehicles is another drawback that is especially relevant today. Cars today have such a high center of gravity, and their batteries can only store so much energy. As a result, the range of an electronic vehicle is significantly lower than a gasoline-powered ‘scar. One argument against this shortcoming is that few people travel the kinds of distances that would exhaust an electric car.

The range of today’s electric vehicles is roughly double or quadruple that of what many people need regularly! However, three contemporary movements are contributing to solving the range anxiety issue. The first is the battery company, which develops new techniques to reduce the battery’s overall size and maximize its energy storage capacity.

Fast charging is a solution in the second sector: the charging business. Depending on the size of the battery, conventional recharge can take up to eight hours. The target is to cut this down to a manageable few minutes. The third force is headed toward battery swapping, where an electric vehicle’s depleted battery can be replaced with an ultimately charged one at a charging station.

Many possibilities exist for the future development of electric and hybrid vehicles.

  • Redox Reactors
  • Quick battery charging
  • The development of lighter, more powerful batteries.
  • Battery recycling centers
  • Alternate Vehicle Layouts

Both electric and hybrid cars have great potential.

Roelof Reineman is an authority on electric cars (both conventional and hybrid) and maintains a blog where he discusses all aspects of this mode of transportation. Energy Management Strategies for a Fuel Cell Hybrid Truck was the topic of his thesis for Control Systems Engineering. (The Hytruck).
